JL04V-8A22-22SE-EBH-R
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PLUG FMALE 4P SOLDER CUP
- CategoryCircular Connectors
- Datasheet JL04V-8A22-22SE-EBH-R Datasheet
-
ECAD Model
- Share
In Stock: 166
Can ship immediately
Pricing:
- 1$81.6
- 10$76.8
- 25$74.4
- 50$69.6
- 100$65.76
Quote It
Technical Details
- Series:JL04V
- Package:Bulk
- Part Status:Active
- Connector Type:Plug, Female Sockets
- Number of Positions:4 (3 + PE)
- Shell Size - Insert:22-22
- Shell Size, MIL:-
- Mounting Type:Free Hanging (In-Line), Right Angle
- Mounting Feature:-
- Termination:Solder Cup
- Fastening Type:Threaded
- Orientation:N (Normal)
- Shell Material:Aluminum Alloy
- Shell Finish:Zinc
- Contact Finish - Mating:Silver
- Color:Black
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Material Flammability Rating:-
- Features:Backshell, Coupling Nut, Ground Lug
- Shielding:-
- Current Rating (Amps):46A
- Voltage Rating:-
- Cable Opening:-
- Operating Temperature:-55°C ~ 125°C
