W8A82-8PG-528
Switchcraft / Conxall
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT MALE 8P GOLD SLDR CUP
- CategoryCircular Connectors
- Datasheet W8A82-8PG-528 Datasheet
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
- 1$14.39
- 10$13.36304
- 25$11.99258
- 50$11.64991
- 100$10.48084
Quote It
Technical Details
- Series:Mini-Con-X®
- Package:Bulk
- Part Status:Active
- Connector Type:Receptacle, Male Pins
- Number of Positions:8 (6 + 2 Power)
- Shell Size - Insert:-
- Shell Size, MIL:-
- Mounting Type:Free Hanging (In-Line)
- Mounting Feature:-
- Termination:Solder Cup
- Fastening Type:Bayonet Lock
- Orientation:Keyed
- Shell Material:Thermoplastic
- Shell Finish:-
- Contact Finish - Mating:Gold
- Color:Black
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Material Flammability Rating:-
- Features:Backshell, UV Resistant
- Shielding:Unshielded
- Current Rating (Amps):2A, 10A
- Voltage Rating:250V
- Cable Opening:0.260" ~ 0.285" (6.60mm ~ 7.24mm)
- Operating Temperature:-40°C ~ 85°C
