3282-9PG-324
Switchcraft / Conxall
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PLUG MALE 9P GOLD SLDR CUP
- CategoryCircular Connectors
- Datasheet 3282-9PG-324 Datasheet
-
ECAD Model
- Share
In Stock: 161
Can ship immediately
Pricing:
- 1$17.05
- 10$15.8317
- 25$14.20758
- 50$13.80155
- 100$12.17784
- 250$11.36598
- 500$11.12242
Quote It
Technical Details
- Series:Multi-Con-X®
- Package:Bulk
- Part Status:Active
- Connector Type:Plug, Male Pins
- Number of Positions:9
- Shell Size - Insert:-
- Shell Size, MIL:-
- Mounting Type:Free Hanging (In-Line)
- Mounting Feature:-
- Termination:Solder Cup
- Fastening Type:Bayonet Lock
- Orientation:Keyed
- Shell Material:Polyamide (PA), Nylon
- Shell Finish:-
- Contact Finish - Mating:Gold
- Color:Black
- Ingress Protection:Weathertight
- Material Flammability Rating:-
- Features:Backshell
- Shielding:Unshielded
- Current Rating (Amps):5.6A
- Voltage Rating:600V
- Cable Opening:0.240" ~ 0.270" (6.10mm ~ 6.86mm)
- Operating Temperature:-40°C ~ 115°C
