6282-7SG-315
Switchcraft / Conxall
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PLUG FMALE 7P GOLD SLDR CUP
- CategoryCircular Connectors
- Datasheet 6282-7SG-315 Datasheet
-
ECAD Model
- Share
In Stock: 200
Can ship immediately
Pricing:
- 1$18.69
- 10$17.35048
- 25$15.57034
- 50$15.12558
- 100$13.3461
- 250$12.45636
- 500$12.18944
Quote It
Technical Details
- Series:Mini-Con-X®
- Package:Bulk
- Part Status:Active
- Connector Type:Plug, Female Sockets
- Number of Positions:7
- Shell Size - Insert:-
- Shell Size, MIL:-
- Mounting Type:Free Hanging (In-Line)
- Mounting Feature:-
- Termination:Solder Cup
- Fastening Type:Bayonet Lock
- Orientation:Keyed
- Shell Material:Polyamide (PA), Nylon
- Shell Finish:-
- Contact Finish - Mating:Gold
- Color:Black
- Ingress Protection:Weathertight
- Material Flammability Rating:-
- Features:Backshell
- Shielding:Unshielded
- Current Rating (Amps):5.6A
- Voltage Rating:600V
- Cable Opening:0.150" ~ 0.170" (3.81mm ~ 4.32mm)
- Operating Temperature:-40°C ~ 115°C
