JB5DS05MM11N
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PLUG MALE 5POS SOLDER CUP
- CategoryCircular Connectors
- Datasheet JB5DS05MM11N Datasheet
-
ECAD Model
- Share
In Stock: 147
Can ship immediately
Pricing:
- 1$30.76143
- 14$30.76143
Quote It
Technical Details
- Series:JB5
- Package:Tray
- Part Status:Active
- Connector Type:Plug, Male Pins
- Number of Positions:5
- Shell Size - Insert:S
- Shell Size, MIL:-
- Mounting Type:Free Hanging (In-Line)
- Mounting Feature:-
- Termination:Solder Cup
- Fastening Type:Push-Pull
- Orientation:N (Normal)
- Shell Material:Zinc Alloy
- Shell Finish:Nickel
- Contact Finish - Mating:Gold
- Color:Black, Silver
- Ingress Protection:IP68 - Dust Tight, Waterproof
- Material Flammability Rating:-
- Features:Clamp, Strain Relief
- Shielding:Shielded
- Current Rating (Amps):3A
- Voltage Rating:320VAC
- Cable Opening:-
- Operating Temperature:-55°C ~ 85°C
