JN2AW05FH1
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT FMALE 5P SOLDER CUP
- CategoryCircular Connectors
- Datasheet JN2AW05FH1 Datasheet
-
ECAD Model
- Share
In Stock: 160
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:JN2W
- Package:Bulk
- Part Status:Obsolete
- Connector Type:Receptacle, Female Sockets
- Number of Positions:5 (4 Power + PE)
- Shell Size - Insert:W
- Shell Size, MIL:-
- Mounting Type:Panel Mount
- Mounting Feature:Flange
- Termination:Solder Cup
- Fastening Type:Push-Twist
- Orientation:N (Normal)
- Shell Material:Zinc Alloy
- Shell Finish:Zinc
- Contact Finish - Mating:Silver
- Color:Black
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Material Flammability Rating:-
- Features:Ground Lug
- Shielding:-
- Current Rating (Amps):13A
- Voltage Rating:400VAC
- Cable Opening:-
- Operating Temperature:-20°C ~ 100°C
