TXD2SA-2M-24V-Z
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE DPDT 1A 24VDC
- Category
- Datasheet TXD2SA-2M-24V-Z Datasheet
-
ECAD Model
- Share
In Stock: 102
Can ship immediately
Pricing:
- 1$3.675
- 500$3.675
Quote It
Technical Details
- Series:TX-D
- Package:Tape & Reel (TR)
- Part Status:Active
- Mounting Type:Surface Mount
- Coil Voltage:24VDC
- Contact Form:DPDT (2 Form D)
- Contact Rating (Current):1 A
- Switching Voltage:110VDC - Max
- Coil Current:11.3 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:Gull Wing
- Seal Rating:Sealed - Fully
- Coil Insulation:-
- Must Operate Voltage:18 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:4 ms
- Release Time:4 ms
- Operating Temperature:-40°C ~ 85°C
- Contact Material:Silver (Ag), Gold (Au)
- Relay Type:General Purpose
