TXD2SL-24V
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE DPDT 2A 24VDC
- Category
- Datasheet TXD2SL-24V Datasheet
-
ECAD Model
- Share
In Stock: 144
Can ship immediately
Pricing:
- 1$4.52
- 40$4.52
Quote It
Technical Details
- Series:TX-D
- Package:Tube
- Part Status:Active
- Mounting Type:Surface Mount
- Coil Voltage:24VDC
- Contact Form:DPDT (2 Form C)
- Contact Rating (Current):2 A
- Switching Voltage:220VDC - Max
- Coil Current:9.6 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:Gull Wing
- Seal Rating:Sealed - Fully
- Coil Insulation:-
- Must Operate Voltage:18 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:4 ms
- Release Time:4 ms
- Operating Temperature:-40°C ~ 85°C
- Contact Material:Silver (Ag), Gold (Au)
- Relay Type:General Purpose
