TXD2SA-24V-4-X
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOS DPDT 10MA 24VDC
- Category
- Datasheet TXD2SA-24V-4-X Datasheet
-
ECAD Model
- Share
In Stock: 158
Can ship immediately
Pricing:
- 1$5.7
- 500$5.7
Quote It
Technical Details
- Series:TX-D
- Package:Tape & Reel (TR)
- Part Status:Active
- Mounting Type:Surface Mount
- Coil Voltage:24VDC
- Contact Form:DPDT (2 Form C)
- Contact Rating (Current):10 mA
- Switching Voltage:10VDC - Max
- Coil Current:12.9 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:Gull Wing
- Seal Rating:Sealed - Fully
- Coil Insulation:-
- Must Operate Voltage:18 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:4 ms
- Release Time:4 ms
- Operating Temperature:-40°C ~ 85°C
- Contact Material:Silver Palladium (AgPd), Gold (Au)
- Relay Type:General Purpose
