TK1-12V
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPDT 2A 12VDC
- Category
- Datasheet TK1-12V Datasheet
-
ECAD Model
- Share
In Stock: 158
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:TK
- Package:Tube
- Part Status:Obsolete
- Mounting Type:Through Hole
- Coil Voltage:12VDC
- Contact Form:SPDT (1 Form C)
- Contact Rating (Current):2 A
- Switching Voltage:220VDC - Max
- Coil Current:11.7 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Fully
- Coil Insulation:-
- Must Operate Voltage:9 VDC
- Must Release Voltage:1.2 VDC
- Operate Time:3 ms
- Release Time:2 ms
- Operating Temperature:-40°C ~ 85°C
- Contact Material:Silver (Ag), Gold (Au)
- Relay Type:General Purpose
