DSBT2-S-DC24V
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE DPDT 2A 24VDC
- Category
- Datasheet DSBT2-S-DC24V Datasheet
-
ECAD Model
- Share
In Stock: 118
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:DS-BT
- Package:Tube
- Part Status:Obsolete
- Mounting Type:Through Hole
- Coil Voltage:24VDC
- Contact Form:DPDT (2 Form C)
- Contact Rating (Current):2 A
- Switching Voltage:250VAC, 220VDC - Max
- Coil Current:15 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:-
- Coil Insulation:-
- Must Operate Voltage:18 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:3 ms
- Release Time:2 ms
- Operating Temperature:-40°C ~ 70°C
- Contact Material:Silver (Ag), Gold (Au)
- Relay Type:General Purpose
