ALQ309
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPST 10A 9V
- Category
- Datasheet ALQ309 Datasheet
-
ECAD Model
- Share
In Stock: 189
Can ship immediately
Pricing:
- 1$2.33
- 10$2.18817
- 25$1.94504
- 50$1.84779
- 100$1.75054
- 300$1.55603
- 500$1.45878
- 1,000$1.36153
- 5,000$1.3129
Quote It
Technical Details
- Series:ALQ
- Package:Box
- Part Status:Active
- Mounting Type:Through Hole
- Coil Voltage:9VDC
- Contact Form:SPST-NO (1 Form A)
- Contact Rating (Current):10 A
- Switching Voltage:250VAC - Max
- Coil Current:22.2 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:-
- Coil Insulation:Class B
- Must Operate Voltage:6.75 VDC
- Must Release Voltage:0.45 VDC
- Operate Time:20 ms
- Release Time:20 ms
- Operating Temperature:-40°C ~ 85°C
- Contact Material:Silver Nickel (AgNi)
- Relay Type:General Purpose
