T9AS1D12-24
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPST 30A 24V
- Category
- Datasheet T9AS1D12-24 Datasheet
-
ECAD Model
- Share
In Stock: 132
Can ship immediately
Pricing:
- 1$5.6
- 10$5.24692
- 25$4.66393
- 50$4.43073
- 100$4.19753
- 250$3.73115
- 500$3.49795
- 1,000$3.26475
- 5,000$3.14815
Quote It
Technical Details
- Series:T9A
- Package:Bulk
- Part Status:Active
- Mounting Type:Through Hole
- Coil Voltage:24VDC
- Contact Form:SPST-NO (1 Form A)
- Contact Rating (Current):30 A
- Switching Voltage:277VAC - Max
- Coil Current:41.7 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Fully
- Coil Insulation:Class F
- Must Operate Voltage:18 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:15 ms
- Release Time:15 ms
- Operating Temperature:-55°C ~ 85°C
- Contact Material:Silver Cadmium Oxide (AgCdO)
- Relay Type:General Purpose
