RZ03-1C4-D024
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPDT 16A 24V
- Category
- Datasheet RZ03-1C4-D024 Datasheet
-
ECAD Model
- Share
In Stock: 161
Can ship immediately
Pricing:
- 1$2.08
- 20$1.95307
- 40$1.73607
- 60$1.64926
- 100$1.56246
- 260$1.38885
- 500$1.30205
- 1,000$1.21524
- 5,000$1.17184
Quote It
Technical Details
- Series:RZ, SCHRACK
- Package:Tube
- Part Status:Active
- Mounting Type:Through Hole
- Coil Voltage:24VDC
- Contact Form:SPDT (1 Form C)
- Contact Rating (Current):16 A
- Switching Voltage:400VAC - Max
- Coil Current:16.7 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:-
- Coil Insulation:Class F
- Must Operate Voltage:16.8 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:8 ms
- Release Time:6 ms
- Operating Temperature:-40°C ~ 85°C
- Contact Material:Silver Nickel (AgNi)
- Relay Type:General Purpose
