JS1-F-48V-F
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPDT 10A 48V
- Category
- Datasheet JS1-F-48V-F Datasheet
-
ECAD Model
- Share
In Stock: 111
Can ship immediately
Pricing:
- 1$2.79
- 10$2.61613
- 25$2.325
- 50$2.20875
- 100$2.0925
- 300$1.86
- 500$1.74375
- 1,000$1.6275
- 5,000$1.56938
Quote It
Technical Details
- Series:JS
- Package:Tube
- Part Status:Not For New Designs
- Mounting Type:Through Hole
- Coil Voltage:48VDC
- Contact Form:SPDT (1 Form C)
- Contact Rating (Current):10 A
- Switching Voltage:250VAC, 100VDC - Max
- Coil Current:7.5 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:-
- Coil Insulation:Class F
- Must Operate Voltage:33.6 VDC
- Must Release Voltage:4.8 VDC
- Operate Time:10 ms
- Release Time:10 ms
- Operating Temperature:-40°C ~ 105°C
- Contact Material:Silver Tin Oxide (AgSnO)
- Relay Type:General Purpose
