OJE-SS-105HM,000
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPST 10A 5V
- Category
- Datasheet OJE-SS-105HM,000 Datasheet
-
ECAD Model
- Share
In Stock: 117
Can ship immediately
Pricing:
- 1$1.43
- 10$1.33955
- 25$1.19052
- 50$1.13091
- 100$1.07138
- 250$0.95235
- 500$0.89282
- 1,000$0.83331
- 5,000$0.80354
Quote It
Technical Details
- Series:OJE, OEG
- Package:Bulk
- Part Status:Active
- Mounting Type:Through Hole
- Coil Voltage:5VDC
- Contact Form:SPST-NO (1 Form A)
- Contact Rating (Current):10 A
- Switching Voltage:277VAC, 30VDC - Max
- Coil Current:91 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Flux Protection
- Coil Insulation:-
- Must Operate Voltage:3.5 VDC
- Must Release Voltage:0.25 VDC
- Operate Time:10 ms
- Release Time:4 ms
- Operating Temperature:-30°C ~ 70°C
- Contact Material:Silver (Ag)
- Relay Type:General Purpose
