LKG1AF-24V-16
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPST 16A 24V
- Category
- Datasheet LKG1AF-24V-16 Datasheet
-
ECAD Model
- Share
In Stock: 128
Can ship immediately
Pricing:
- 1$2.35
- 10$2.205
- 25$1.96
- 50$1.862
- 100$1.764
- 250$1.568
- 500$1.47
- 1,000$1.372
- 5,000$1.323
Quote It
Technical Details
- Series:LK-G
- Package:Box
- Part Status:Not For New Designs
- Mounting Type:Through Hole
- Coil Voltage:24VDC
- Contact Form:SPST-NO (1 Form A)
- Contact Rating (Current):16 A
- Switching Voltage:277VAC - Max
- Coil Current:22.1 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Flux Protection
- Coil Insulation:-
- Must Operate Voltage:18 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:15 ms
- Release Time:20 ms
- Operating Temperature:-40°C ~ 70°C
- Contact Material:Silver Tin Oxide (AgSnO)
- Relay Type:General Purpose
