JTV1S-PA-24V
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPST 20A 24V
- Category
- Datasheet JTV1S-PA-24V Datasheet
-
ECAD Model
- Share
In Stock: 121
Can ship immediately
Pricing:
- 1$4.42
- 10$4.14
- 25$3.68
- 50$3.496
- 100$3.312
- 250$2.944
- 500$2.76
- 1,000$2.576
Quote It
Technical Details
- Series:JT-V
- Package:Bulk
- Part Status:Not For New Designs
- Mounting Type:Through Hole
- Coil Voltage:24VDC
- Contact Form:SPST-NO (1 Form A)
- Contact Rating (Current):20 A
- Switching Voltage:277VAC - Max
- Coil Current:41.7 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Fully
- Coil Insulation:-
- Must Operate Voltage:18 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:15 ms
- Release Time:10 ms
- Operating Temperature:-55°C ~ 85°C
- Contact Material:Silver Tin Oxide (AgSnO)
- Relay Type:General Purpose
