9-1415536-1
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE DPDT 6A 24V
- Category
- Datasheet 9-1415536-1 Datasheet
-
ECAD Model
- Share
In Stock: 114
Can ship immediately
Pricing:
- 1$82.71
- 10$78.35753
- 25$74.00425
- 50$69.65098
- 100$65.29781
Quote It
Technical Details
- Series:SR2Z, SCHRACK
- Package:Bulk
- Part Status:Active
- Mounting Type:DIN Rail
- Coil Voltage:24VDC
- Contact Form:DPDT (2 Form C)
- Contact Rating (Current):6 A
- Switching Voltage:250VAC - Max
- Coil Current:29.2 mA
- Coil Type:Non Latching
- Features:Socket Included
- Termination Style:Spring Terminal
- Seal Rating:-
- Coil Insulation:-
- Must Operate Voltage:21.6 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:-
- Release Time:-
- Operating Temperature:-25°C ~ 50°C
- Contact Material:Silver Nickel (AgNi)
- Relay Type:General Purpose
