- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE DPDT 12A 220V
- Category
- Datasheet PT270220 Datasheet
-
ECAD Model
- Share
In Stock: 153
Can ship immediately
Pricing:
- 1$19.64
- 10$17.45222
- 25$16.57961
- 50$15.707
- 100$14.83439
- 250$13.52547
- 500$12.65286
- 1,000$11.9984
Quote It
Technical Details
- Series:PT, SCHRACK
- Package:Bulk
- Part Status:Active
- Mounting Type:Socketable
- Coil Voltage:220VDC
- Contact Form:DPDT (2 Form C)
- Contact Rating (Current):12 A
- Switching Voltage:400VAC - Max
- Coil Current:3.4 mA
- Coil Type:Non Latching
- Features:Mechanical Indicator, Test Button
- Termination Style:Plug In, Quick Connect - 0.110" (2.8mm)
- Seal Rating:-
- Coil Insulation:-
- Must Operate Voltage:165 VDC
- Must Release Voltage:22 VDC
- Operate Time:15 ms
- Release Time:10 ms
- Operating Temperature:-40°C ~ 70°C
- Contact Material:Silver Nickel (AgNi)
- Relay Type:General Purpose
