KUP-14A25-120
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE 3PDT 10A 120V
- Category
- Datasheet KUP-14A25-120 Datasheet
-
ECAD Model
- Share
In Stock: 183
Can ship immediately
Pricing:
- 1$22.56
- 10$21.432
- 25$20.304
- 50$19.176
- 100$18.048
- 250$16.92
- 500$15.792
Quote It
Technical Details
- Series:KUP
- Package:Bulk
- Part Status:Active
- Mounting Type:Socketable
- Coil Voltage:120VAC
- Contact Form:3PDT (3 Form C)
- Contact Rating (Current):10 A
- Switching Voltage:240VAC - Max
- Coil Current:24 mA
- Coil Type:Non Latching
- Features:Test Button
- Termination Style:Plug In, Quick Connect - 0.187" (4.7mm)
- Seal Rating:-
- Coil Insulation:-
- Must Operate Voltage:102 VAC
- Must Release Voltage:-
- Operate Time:15 ms
- Release Time:10 ms
- Operating Temperature:-45°C ~ 45°C
- Contact Material:Silver Cadmium Oxide (AgCdO)
- Relay Type:General Purpose
