KUHP-5DT1-24
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPDT 30A 24V
- Category
- Datasheet KUHP-5DT1-24 Datasheet
-
ECAD Model
- Share
In Stock: 158
Can ship immediately
Pricing:
- 1$37.1
- 10$35.245
- 25$33.39
- 50$31.535
- 100$29.68
- 250$27.825
Quote It
Technical Details
- Series:KUHP
- Package:Bulk
- Part Status:Active
- Mounting Type:Chassis Mount
- Coil Voltage:24VDC
- Contact Form:SPDT (1 Form C)
- Contact Rating (Current):30 A
- Switching Voltage:240VAC - Max
- Coil Current:51 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:Quick Connect - 0.250" (6.3mm)
- Seal Rating:-
- Coil Insulation:Class B
- Must Operate Voltage:18 VDC
- Must Release Voltage:-
- Operate Time:20 ms
- Release Time:20 ms
- Operating Temperature:-45°C ~ 70°C
- Contact Material:Silver Cadmium Oxide (AgCdO)
- Relay Type:General Purpose
