ALZ52B48T
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionALZ RELAY 1 FORM A 48V
- Category
- Datasheet ALZ52B48T Datasheet
-
ECAD Model
- Share
In Stock: 142
Can ship immediately
Pricing:
- 1$3.8925
- 20$3.8925
Quote It
Technical Details
- Series:ALZ
- Package:Tube
- Part Status:Active
- Mounting Type:Through Hole
- Coil Voltage:48VDC
- Contact Form:SPST-NO (1 Form A)
- Contact Rating (Current):16 A
- Switching Voltage:440VAC - Max
- Coil Current:8.3 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Fully
- Coil Insulation:Class B
- Must Operate Voltage:33.6 VDC
- Must Release Voltage:4.8 VDC
- Operate Time:15 ms
- Release Time:5 ms
- Operating Temperature:-40°C ~ 85°C
- Contact Material:Silver Tin Oxide (AgSnO)
- Relay Type:General Purpose
