JVN1AF-18V-F
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPST 16A 18V
- Category
- Datasheet JVN1AF-18V-F Datasheet
-
ECAD Model
- Share
In Stock: 148
Can ship immediately
Pricing:
- 1$5.184
- 100$5.184
Quote It
Technical Details
- Series:JV-N
- Package:Bulk
- Part Status:Active
- Mounting Type:Through Hole
- Coil Voltage:18VDC
- Contact Form:SPST-NO (1 Form A)
- Contact Rating (Current):16 A
- Switching Voltage:277VAC, 30VDC - Max
- Coil Current:11.1 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Flux Protection
- Coil Insulation:-
- Must Operate Voltage:13.5 VDC
- Must Release Voltage:0.9 VDC
- Operate Time:12 ms
- Release Time:5 ms
- Operating Temperature:-40°C ~ 70°C
- Contact Material:Silver Tin Oxide (AgSnO)
- Relay Type:General Purpose
