SP2-DC6V
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE DPDT 15A 6V
- Category
- Datasheet SP2-DC6V Datasheet
-
ECAD Model
- Share
In Stock: 138
Can ship immediately
Pricing:
- 1$22.553
- 20$22.553
Quote It
Technical Details
- Series:SP
- Package:Tube
- Part Status:Active
- Mounting Type:Socketable
- Coil Voltage:6VDC
- Contact Form:DPDT (2 Form C)
- Contact Rating (Current):15 A
- Switching Voltage:250VAC, 30VDC - Max
- Coil Current:50 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:Plug In, Quick Connect - 0.187" (4.7mm)
- Seal Rating:-
- Coil Insulation:-
- Must Operate Voltage:4.2 VDC
- Must Release Voltage:0.6 VDC
- Operate Time:30 ms
- Release Time:20 ms
- Operating Temperature:-50°C ~ 60°C
- Contact Material:Silver Tin Oxide (AgSnO)
- Relay Type:General Purpose
