HE2AN-S-AC120V
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE DPST 25A 120V
- Category
- Datasheet HE2AN-S-AC120V Datasheet
-
ECAD Model
- Share
In Stock: 144
Can ship immediately
Pricing:
- 1$28.88
- 20$28.88
Quote It
Technical Details
- Series:HE
- Package:Bulk
- Part Status:Active
- Mounting Type:Chassis Mount
- Coil Voltage:120VAC
- Contact Form:DPST-NO (2 Form A)
- Contact Rating (Current):25 A
- Switching Voltage:277VAC, 30VDC - Max
- Coil Current:22.1 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:Screw Terminal
- Seal Rating:-
- Coil Insulation:-
- Must Operate Voltage:84 VAC
- Must Release Voltage:18 VAC
- Operate Time:30 ms
- Release Time:30 ms
- Operating Temperature:-50°C ~ 55°C
- Contact Material:Silver Tin Oxide (AgSnO)
- Relay Type:General Purpose
