T9EV1D14-22
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPST 30A 22V
- Category
- Datasheet T9EV1D14-22 Datasheet
-
ECAD Model
- Share
In Stock: 140
Can ship immediately
Pricing:
- 1$2.772
- 1,000$2.478
Quote It
Technical Details
- Series:T9E
- Package:Bulk
- Part Status:Active
- Mounting Type:Through Hole
- Coil Voltage:22VDC
- Contact Form:SPST-NO (1 Form A)
- Contact Rating (Current):30 A
- Switching Voltage:250VAC - Max
- Coil Current:45.5 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Flux Protection
- Coil Insulation:Class F
- Must Operate Voltage:16.5 VDC
- Must Release Voltage:2.2 VDC
- Operate Time:15 ms
- Release Time:15 ms
- Operating Temperature:-40°C ~ 85°C
- Contact Material:Silver Tin Oxide Indium Oxide (AgSnOInO)
- Relay Type:General Purpose
