T9ES5D12-24
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPDT 20A 24V
- Category
- Datasheet T9ES5D12-24 Datasheet
-
ECAD Model
- Share
In Stock: 178
Can ship immediately
Pricing:
- 1$3.525
- 500$3.135
Quote It
Technical Details
- Series:T9E
- Package:Bulk
- Part Status:Active
- Mounting Type:Through Hole
- Coil Voltage:24VDC
- Contact Form:SPDT (1 Form C)
- Contact Rating (Current):20 A
- Switching Voltage:250VAC - Max
- Coil Current:41.7 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Fully
- Coil Insulation:Class F
- Must Operate Voltage:18 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:15 ms
- Release Time:15 ms
- Operating Temperature:-40°C ~ 85°C
- Contact Material:Silver Tin Oxide Indium Oxide (AgSnOInO)
- Relay Type:General Purpose
