G2R-1A-E-T130 DC5
Omron Electronics Components
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPST 16A 5V
- Category
- Datasheet G2R-1A-E-T130 DC5 Datasheet
-
ECAD Model
- Share
In Stock: 111
Can ship immediately
Pricing:
- 1$5.5919
- 100$5.5919
Quote It
Technical Details
- Series:G2R
- Package:Tray
- Part Status:Active
- Mounting Type:Through Hole
- Coil Voltage:5VDC
- Contact Form:SPST-NO (1 Form A)
- Contact Rating (Current):16 A
- Switching Voltage:380VAC, 125VDC - Max
- Coil Current:106 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Flux Protection
- Coil Insulation:-
- Must Operate Voltage:3.5 VDC
- Must Release Voltage:0.75 VDC
- Operate Time:15 ms
- Release Time:5 ms
- Operating Temperature:-40°C ~ 70°C
- Contact Material:Silver Alloy
- Relay Type:General Purpose
