G2R-1B-E AC24
Omron Electronics Components- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPST 16A 24V
- Category
- Datasheet G2R-1B-E AC24 Datasheet
-
ECAD Model
- Share
In Stock: 182
Can ship immediately
Pricing:
- 1$8.6816
- 100$8.2475
Quote It
Technical Details
- Series:G2R
- Package:Tube
- Part Status:Active
- Mounting Type:Through Hole
- Coil Voltage:24VAC
- Contact Form:SPST-NC (1 Form B)
- Contact Rating (Current):16 A
- Switching Voltage:380VAC, 125VDC - Max
- Coil Current:37.4 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Flux Protection
- Coil Insulation:-
- Must Operate Voltage:19.2 VAC
- Must Release Voltage:7.2 VAC
- Operate Time:15 ms
- Release Time:10 ms
- Operating Temperature:-40°C ~ 70°C
- Contact Material:Silver Alloy
- Relay Type:General Purpose
