PRD-3DH0-24
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPST 20A 24V
- Category
- Datasheet PRD-3DH0-24 Datasheet
-
ECAD Model
- Share
In Stock: 189
Can ship immediately
Pricing:
- 1$41.22
- 40$36.738
Quote It
Technical Details
- Series:PRD
- Package:Bulk
- Part Status:Active
- Mounting Type:Chassis Mount
- Coil Voltage:24VDC
- Contact Form:SPST-NO (DM) (1 Form X)
- Contact Rating (Current):20 A
- Switching Voltage:125VDC - Nom
- Coil Current:84 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:Screw Terminal
- Seal Rating:-
- Coil Insulation:Class B
- Must Operate Voltage:18 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:40 ms
- Release Time:20 ms
- Operating Temperature:-55°C ~ 80°C
- Contact Material:Silver (Ag)
- Relay Type:General Purpose
