PRD-11DG1-24
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE DPDT 30A 24V
- Category
- Datasheet PRD-11DG1-24 Datasheet
-
ECAD Model
- Share
In Stock: 176
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:PRD
- Package:Bulk
- Part Status:Active
- Mounting Type:Chassis Mount
- Coil Voltage:24VDC
- Contact Form:DPDT (2 Form C)
- Contact Rating (Current):30 A
- Switching Voltage:240VAC - Nom
- Coil Current:84 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:Quick Connect - 0.250" (6.3mm)
- Seal Rating:-
- Coil Insulation:Class B
- Must Operate Voltage:18 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:40 ms
- Release Time:20 ms
- Operating Temperature:-55°C ~ 80°C
- Contact Material:Silver Cadmium Oxide (AgCdO)
- Relay Type:General Purpose
