PRD-3DG0-24

Technical Details

• Series:PRD
• Package:Bulk
• Part Status:Active
• Mounting Type:Chassis Mount
• Coil Voltage:24VDC
• Contact Form:SPST-NO (DM) (1 Form X)
• Contact Rating (Current):30 A
• Switching Voltage:277VAC - Nom
• Coil Current:84 mA
• Coil Type:Non Latching
• Features:-

• Termination Style:Screw Terminal
• Seal Rating:-
• Coil Insulation:Class B
• Must Operate Voltage:18 VDC
• Must Release Voltage:2.4 VDC
• Operate Time:40 ms
• Release Time:20 ms
• Operating Temperature:-55°C ~ 80°C
• Contact Material:Silver Cadmium Oxide (AgCdO)
• Relay Type:General Purpose
