S90R11ABD1-24
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY IMPULSE DPDT 20A 24V
- Category
- Datasheet S90R11ABD1-24 Datasheet
-
ECAD Model
- Share
In Stock: 183
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:S90R
- Package:Bulk
- Part Status:Obsolete
- Mounting Type:Chassis Mount
- Coil Voltage:24VAC
- Contact Form:DPDT (2 Form C)
- Contact Rating (Current):20 A
- Switching Voltage:277VAC - Max
- Coil Current:375 mA
- Coil Type:Latching, Single Coil
- Features:-
- Termination Style:Quick Connect - 0.250" (6.3mm)
- Seal Rating:-
- Coil Insulation:Class B
- Must Operate Voltage:20.4 VAC
- Must Release Voltage:-
- Operate Time:-
- Release Time:-
- Operating Temperature:-10°C ~ 60°C
- Contact Material:-
- Relay Type:Impulse
