S87R5A2B1D1-120
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPDT 20A 120V
- Category
- Datasheet S87R5A2B1D1-120 Datasheet
-
ECAD Model
- Share
In Stock: 195
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:S87R
- Package:Tray
- Part Status:Obsolete
- Mounting Type:Chassis Mount
- Coil Voltage:120VAC
- Contact Form:SPDT (1 Form C)
- Contact Rating (Current):20 A
- Switching Voltage:277VAC - Max
- Coil Current:33 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:Quick Connect - 0.250" (6.3mm)
- Seal Rating:-
- Coil Insulation:Class B
- Must Operate Voltage:102 VAC
- Must Release Voltage:-
- Operate Time:-
- Release Time:-
- Operating Temperature:-10°C ~ 65°C
- Contact Material:Silver Cadmium Oxide (AgCdO)
- Relay Type:General Purpose
