- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE DPDT 12A 115V
- Category
- Datasheet PT271615 Datasheet
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:PT, SCHRACK
- Package:Bulk
- Part Status:Obsolete
- Mounting Type:Through Hole
- Coil Voltage:115VAC
- Contact Form:DPDT (2 Form C)
- Contact Rating (Current):12 A
- Switching Voltage:400VAC - Max
- Coil Current:-
- Coil Type:Non Latching
- Features:Mechanical Indicator, Test Button
- Termination Style:PC Pin
- Seal Rating:-
- Coil Insulation:-
- Must Operate Voltage:92 VAC
- Must Release Voltage:34.5 VAC
- Operate Time:-
- Release Time:-
- Operating Temperature:-40°C ~ 70°C
- Contact Material:Silver Nickel (AgNi)
- Relay Type:General Purpose
