- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE DPDT 25A 12V
- Category
- Datasheet RM835012 Datasheet
-
ECAD Model
- Share
In Stock: 161
Can ship immediately
Pricing:
- 1$20.38
- 10$19.365
- 25$18.3456
- 50$17.3264
- 100$16.9442
Quote It
Technical Details
- Series:RM, SCHRACK
- Package:Bulk
- Part Status:Obsolete
- Mounting Type:Chassis Mount
- Coil Voltage:12VDC
- Contact Form:DPDT (2 Form C)
- Contact Rating (Current):25 A
- Switching Voltage:400VAC - Max
- Coil Current:109 mA
- Coil Type:Non Latching
- Features:Mechanical Indicator, Test Button
- Termination Style:Quick Connect - 0.250" (6.3mm)
- Seal Rating:-
- Coil Insulation:-
- Must Operate Voltage:9 VDC
- Must Release Voltage:1.2 VDC
- Operate Time:15 ms
- Release Time:10 ms
- Operating Temperature:-45°C ~ 65°C
- Contact Material:Silver Cadmium Oxide (AgCdO)
- Relay Type:General Purpose
