T7NS5D1-18
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPDT 10A 18V
- Category
- Datasheet T7NS5D1-18 Datasheet
-
ECAD Model
- Share
In Stock: 103
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:T7N
- Package:Tube
- Part Status:Obsolete
- Mounting Type:Through Hole
- Coil Voltage:18VDC
- Contact Form:SPDT (1 Form C)
- Contact Rating (Current):10 A
- Switching Voltage:240VAC, 28VDC - Max
- Coil Current:20 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Fully
- Coil Insulation:Class F
- Must Operate Voltage:12.6 VDC
- Must Release Voltage:1.8 VDC
- Operate Time:9 ms
- Release Time:5 ms
- Operating Temperature:-40°C ~ 85°C
- Contact Material:Silver Cadmium Oxide (AgCdO)
- Relay Type:General Purpose
