T73S1D15-12

Technical Details

• Series:T73
• Package:Tube
• Part Status:Obsolete
• Mounting Type:Through Hole
• Coil Voltage:12VDC
• Contact Form:SPST-NO (1 Form A)
• Contact Rating (Current):10 A
• Switching Voltage:120VAC, 28VDC - Max
• Coil Current:37.5 mA
• Coil Type:Non Latching
• Features:-

• Termination Style:PC Pin
• Seal Rating:Sealed - Fully
• Coil Insulation:Class F
• Must Operate Voltage:7.8 VDC
• Must Release Voltage:0.6 VDC
• Operate Time:10 ms
• Release Time:5 ms
• Operating Temperature:-30°C ~ 80°C
• Contact Material:Silver Cadmium Oxide (AgCdO)
• Relay Type:General Purpose
