KUP-11D56-24
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE DPDT 10A 24V
- Category
- Datasheet KUP-11D56-24 Datasheet
-
ECAD Model
- Share
In Stock: 106
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:KUP
- Package:Bulk
- Part Status:Obsolete
- Mounting Type:Chassis Mount
- Coil Voltage:24VDC
- Contact Form:DPDT (2 Form C)
- Contact Rating (Current):10 A
- Switching Voltage:240VAC - Max
- Coil Current:51 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:Quick Connect - 0.205" (5.2mm)
- Seal Rating:-
- Coil Insulation:Class B
- Must Operate Voltage:18 VDC
- Must Release Voltage:-
- Operate Time:15 ms
- Release Time:10 ms
- Operating Temperature:-45°C ~ 70°C
- Contact Material:Silver Cadmium Oxide (AgCdO)
- Relay Type:General Purpose
