G5PA-1-M-EDC5BYOMZ(PF)

Technical Details

• Series:G5PA-1
• Package:Bulk
• Part Status:Obsolete
• Mounting Type:Through Hole
• Coil Voltage:5VDC
• Contact Form:SPST-NO (1 Form A)
• Contact Rating (Current):10 A
• Switching Voltage:277VAC, 30VDC - Max
• Coil Current:108 mA
• Coil Type:Non Latching
• Features:-

• Termination Style:PC Pin
• Seal Rating:Sealed - Flux Protection
• Coil Insulation:-
• Must Operate Voltage:4 VDC
• Must Release Voltage:0.5 VDC
• Operate Time:15 ms
• Release Time:5 ms
• Operating Temperature:-40°C ~ 70°C
• Contact Material:-
• Relay Type:General Purpose
