3-1393231-8
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPDT 12A 24V
- Category
- Datasheet 3-1393231-8 Datasheet
-
ECAD Model
- Share
In Stock: 152
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:RP II/1, SCHRACK
- Package:Tube
- Part Status:Obsolete
- Mounting Type:Through Hole
- Coil Voltage:24VDC
- Contact Form:SPDT (1 Form C)
- Contact Rating (Current):12 A
- Switching Voltage:400VAC - Max
- Coil Current:21.8 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Flux Protection
- Coil Insulation:-
- Must Operate Voltage:16.8 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:8 ms
- Release Time:2 ms
- Operating Temperature:-40°C ~ 70°C
- Contact Material:-
- Relay Type:General Purpose
