- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPST 12A 9V
- Category
- Datasheet T7CS1D-09 Datasheet
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:T7C
- Package:Tube
- Part Status:Obsolete
- Mounting Type:Through Hole
- Coil Voltage:9VDC
- Contact Form:SPST-NO (1 Form A)
- Contact Rating (Current):12 A
- Switching Voltage:240VAC, 28VDC - Max
- Coil Current:40 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Fully
- Coil Insulation:Class F
- Must Operate Voltage:6.75 VDC
- Must Release Voltage:0.45 VDC
- Operate Time:10 ms
- Release Time:5 ms
- Operating Temperature:-30°C ~ 85°C
- Contact Material:Silver Cadmium Oxide (AgCdO)
- Relay Type:General Purpose
