V23061A1003A302
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GENERAL PURPOSE SPST 8A 6V
- Category
- Datasheet V23061A1003A302 Datasheet
-
ECAD Model
- Share
In Stock: 101
Can ship immediately
Pricing:
- 1$5.67
- 20$5.31766
- 40$4.72681
- 60$4.49047
- 100$4.25413
- 260$3.78145
- 500$3.54511
- 1,000$3.30876
Quote It
Technical Details
- Series:MSR, SCHRACK
- Package:Tube
- Part Status:Discontinued at Digi-Key
- Mounting Type:Through Hole
- Coil Voltage:6VDC
- Contact Form:SPST-NO (1 Form A)
- Contact Rating (Current):8 A
- Switching Voltage:400VAC - Max
- Coil Current:36.3 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Fully
- Coil Insulation:Class A
- Must Operate Voltage:4.1 VDC
- Must Release Voltage:0.6 VDC
- Operate Time:10 ms
- Release Time:5 ms
- Operating Temperature:-40°C ~ 85°C
- Contact Material:Silver Tin Oxide (AgSnO)
- Relay Type:General Purpose
