SDT-SS-109DM,000

Technical Details

• Series:SDT, OEG
• Package:Tube
• Part Status:Active
• Mounting Type:Through Hole
• Coil Voltage:9VDC
• Contact Form:SPST-NO (1 Form A)
• Contact Rating (Current):10 A
• Switching Voltage:250VAC, 24VDC - Max
• Coil Current:58 mA
• Coil Type:Non Latching
• Features:-

• Termination Style:PC Pin
• Seal Rating:Sealed - Flux Protection
• Coil Insulation:-
• Must Operate Voltage:6.75 VDC
• Must Release Voltage:0.9 VDC
• Operate Time:15 ms
• Release Time:8 ms
• Operating Temperature:-30°C ~ 60°C
• Contact Material:Silver Tin Oxide Indium Oxide (AgSnOInO)
• Relay Type:General Purpose
