OUDH-SH-109DM,000

Technical Details

• Series:OUDH, OEG
• Package:Tube
• Part Status:Obsolete
• Mounting Type:Through Hole
• Coil Voltage:9VDC
• Contact Form:SPST-NO (1 Form A)
• Contact Rating (Current):10 A
• Switching Voltage:240VAC, 110VDC - Max
• Coil Current:50 mA
• Coil Type:Non Latching
• Features:-

• Termination Style:PC Pin
• Seal Rating:Sealed - Flux Protection
• Coil Insulation:Class A
• Must Operate Voltage:6.75 VDC
• Must Release Voltage:0.9 VDC
• Operate Time:10 ms
• Release Time:5 ms
• Operating Temperature:-30°C ~ 60°C
• Contact Material:Silver Tin Oxide (AgSnO)
• Relay Type:General Purpose
