PCLH-103D1SP,000
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPDT 15A 24V
- Category
- Datasheet PCLH-103D1SP,000 Datasheet
-
ECAD Model
- Share
In Stock: 181
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:PCLH, OEG
- Package:Bulk
- Part Status:Obsolete
- Mounting Type:Through Hole
- Coil Voltage:24VDC
- Contact Form:SPDT (1 Form C)
- Contact Rating (Current):15 A
- Switching Voltage:250VAC, 24VDC - Max
- Coil Current:37.5 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:-
- Coil Insulation:Class F
- Must Operate Voltage:19.2 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:15 ms
- Release Time:8 ms
- Operating Temperature:-40°C ~ 55°C
- Contact Material:Silver Cadmium Oxide (AgCdO)
- Relay Type:General Purpose
