G6M-1A DC4.5

Technical Details

• Series:G6M
• Package:Bulk
• Part Status:Obsolete
• Mounting Type:Through Hole
• Coil Voltage:4.5VDC
• Contact Form:SPST-NO (1 Form A)
• Contact Rating (Current):3 A
• Switching Voltage:270VAC, 125VDC - Max
• Coil Current:26.7 mA
• Coil Type:Non Latching
• Features:-

• Termination Style:PC Pin
• Seal Rating:Sealed - Fully
• Coil Insulation:-
• Must Operate Voltage:3.38 VDC
• Must Release Voltage:0.225 VDC
• Operate Time:10 ms
• Release Time:5 ms
• Operating Temperature:-40°C ~ 85°C
• Contact Material:-
• Relay Type:General Purpose
