HCPL-063L-560

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Discontinued at Digi-Key
• Number of Channels:2
• Inputs - Side 1/Side 2:2/0
• Voltage - Isolation:3750Vrms
• Common Mode Transient Immunity (Min):10kV/µs
• Input Type:DC
• Output Type:Open Collector, Schottky Clamped
• Current - Output / Channel:50 mA

• Data Rate:15MBd
• Propagation Delay tpLH / tpHL (Max):75ns, 75ns
• Rise / Fall Time (Typ):24ns, 10ns
• Voltage - Forward (Vf) (Typ):1.5V
• Current - DC Forward (If) (Max):15mA
• Voltage - Supply:2.7V ~ 3.6V, 4.5V ~ 5.5V
• Operating Temperature:-40°C ~ 85°C
• Mounting Type:Surface Mount
• Package / Case:8-SOIC (0.154", 3.90mm Width)
• Supplier Device Package:8-SO Tall
