3304-1-14-80-00-00-08-0
Mill-Max- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PC PIN CIRC
- CategoryTerminals - PC Pin, Single Post Connectors
- Datasheet 3304-1-14-80-00-00-08-0 Datasheet
-
ECAD Model
- Share
In Stock: 169
Can ship immediately
Pricing:
- 1$0.50112
- 1,000$0.49968
Quote It
Technical Details
- Series:3304
- Package:Bulk
- Part Status:Active
- Terminal Type:PC Pin
- Terminal Style:Single End
- Pin Size - Above Flange:0.040" (1.02mm) Dia
- Pin Size - Below Flange:-
- Length - Above Flange:-
- Length - Below Flange:0.051" (1.30mm)
- Length - Overall:-
- Flange Diameter:0.070" (1.78mm)
- Mounting Hole Diameter:0.043" (1.09mm)
- Mounting Type:Through Hole, Right Angle
- Termination:Swage
- Insulation:Non-Insulated
- Board Thickness:0.031" (0.79mm)
- Contact Material:Brass Alloy
- Contact Finish:Tin
- Contact Finish Thickness:200.0µin (5.08µm)
